Cylon AI Core

  • A pre-flashed kit ready to operate out of the box. The kit includes a Jetson carrier board, an NVIDIA Jetson Orin NX 16 GB USA Made 900-13767-0000-0A0, Swissbit SN3000MB480GI-2MA2-2GB-STD 480GB SSD, and a Jetson heatsink and fan.



Cost: $3,200.00







Does not include MHF4 cables or antennas.
  • Jetson Orin NX/Nano Form Factor
    • Supports Super Power Mode
  • Connectors
    • XT60 Battery Input
      • 75V Max
      • 5.5V Min
      • Built INA238 Power Monitor
      • Built in 5.2V 8A Regulator
    • XT30 Battery Output
      • Measured Output with Power Monitor
    • 5V Digital Power Module Input
    • Gigabit Ethernet
      • RJ45
    • Dual MIPI CSI Camera Inputs
      • 2x – 22 Pin 0.5mm Pitch Raspberry Pi Cam FFC
    • Dual USB 3.2 + USB 2.0 Host Ports
      • 2x – USB A
      • 1.5A Current Limit
    • USB C Dual Mode (OTG) Port
      • 1.5A Current Limit
    • Dual USB 2.0 Host Ports
      • 4 Pin JST-GH
      • 1.0A Current Limit
    • M.2 Key M 2242
      • PCIEx4
    • M.2 Key E 2230
      • PCIEx2
      • USB
      • I2S
    • PCIE 16 Pin FFC Connector
      • Matches Raspberry Pi 5 PCIE Pinout
      • PCIEx2
    • HDMI Full Size Connector
      • HDMI v2.1
    • CAN Port
      • 4 Pin JST-GH
    • SPI/GPIO Port
      • 7 Pin JST-GH
    • I2S/GPIO Port
      • 7 Pin JST-GH
    • UART0/GPIO
      • 6 Pin JST-GH
    • UART1/GPIO
      • 6 Pin JST-GH
    • UART2/I2C0
      • 6 Pin JST-GH
      • Debug Console Defaults to UART2
  • Built in IMU
  • USA Built
  • Power Requirements
    • 5V
    • 4A Minimum
    • Depends on Usage and Peripherals
  • Dimensions Without Jetson
    • 100mm x 72mm x 23mm
  • Weight
    • Without Jetson and M.2 Modules – 75g
